Frame
frame
Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Flat Mount Brake, SIC Mount, FM Kickstand Mount
size
26″
Suspension
Suspension fork
SR Suntour XCE, 80mm
Drivetrain & brakes
brake system
Shimano BR-MT200/UR300, Hydr, Disc Brake, PM/FM (160/160)
rear derailleur
Shimano RD-TX800, 8-Speed
shifters
Shimano SL-M315, Rapidfire-Plus
front derailleur
Shimano FD-M315, Top Swing, 31.8mm Clamp
bottom bracket
Thun Paso-ML, 73mm BSA
crankset
Shimano FC-M315, 36x22T, 170mm
cassette
Shimano CS-HG200, 12-32T
chain
KMC Z8.3
Cockpit
headset
CUBE FPH863, Semi-Integrated
Stem
CUBE Performance Stem, 31.8mm
handlebar
CUBE Rise Trail Bar, 680mm
grips
ACID React
Wheels
rims
CUBE ZX20, 32H, Disc
front hub
CUBE Alloy Light, QR, 6-Bolt
rear hub
CUBE Alloy Light, QR, 6-Bolt
tyres
CUBE MTB 26″
Finishing kit
saddle
ACID Venec Lite
seat post
CUBE Performance Post, 27.2mm
pedals
CUBE PP MTB
Product information
colour
galactic´n´cyan
weight
13,9 kg
