Frame
frame
Aluminium Superlite, Gravity Casting Technology, Efficient Comfort Geometry, Boost148, Fully Integrated Battery, Integrated Carrier 3.0, Advanced Internal Cable Routing, 1.5 Headtube
size
Classic: S / 50cm, M / 54cm, L / 58cm, XL / 62cm
Suspension
Suspension fork
SR Suntour NX1-32 LO Air, Tapered, 15x110mm, 100mm
E-bike system
drive unit
Bosch Drive Unit Performance Line CX 85Nm (BDU38), Smart System
Remote
Bosch Purion 200 w/ Integrated Display
battery
Bosch PowerTube 600
charger
Bosch 2A
Drivetrain & brakes
brake system
Shimano BR-MT200, Hydr. Disc Brake (180/180)
rear derailleur
Shimano Cues RD-U6000-GS, 10-Speed
shifters
Shimano Cues SL-U6000, Rapidfire-Plus
crankset
ACID MTB Hybrid Pro
cassette
Shimano Cues CS-LG300, 11-48T
chain
KMC eGlide
Cockpit
headset
ACROS AZF-1035, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm), HIC
Stem
CUBE Comfort Stem Pro, 31.8mm, Adjustable
handlebar
CUBE Comfort Trail Bar, 700mm
grips
ACID Travel Comfort
Wheels
rims
CUBE EX25, 36H, Disc, Tubeless Ready
front hub
CUBE Engineered By Newmen, 15mm, Boost, Centerlock
rear hub
Shimano FH-MT400-B, 12mm, Boost, Centerlock
tyres
Schwalbe Big Apple, Active, 55-622
Finishing kit
saddle
ACID Sequence Pro Plus
seat post
CUBE Suspension Seatpost HD, 31.6mm
pedals
ACID PP MTB
front light
ACID Front Light PRO-E 60 X-Connect, 12V, DC
rear light
ACID Mudguard Rear Light PRO-E, 12V, DC
kickstand
ACID FM Pure Kickstand
mudguards
ACID 65 Integrated Carrier 3.0
bell
Easy Bell
carrier
ACID Integrated Carrier 3.0, CUBE Adapter Compatible
Product information
colour
shadowgrey´n´black
weight
26,7 kg
Art. No
812050
