Frame
frame
Aluminum Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points, Integrated Seatclamp
size
Size Split: 27.5: S // 29: M L XL
Suspension
Suspension fork
SR Suntour XCR34X 2CR Air, Tapered, 15x110mm, 120mm
shock
SR Suntour EdgeX R 185×52,5mm, Rebound Adjust, Trunnion Mount
shock hardware
Top: 54mm Trunnion Mount, Bottom: 22.2x8mm
E-bike system
drive unit
Bosch Drive Unit Performance Line CX 85Nm (BDU38), Smart System
Remote
Bosch Purion 200 w/ Integrated Display
battery
Bosch PowerTube 600
charger
Bosch 2A
Drivetrain & brakes
brake system
Magura MT Thirty, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
rear derailleur
Shimano Cues RD-U6000-GS, 10-Speed
shifters
Shimano Cues SL-U6000, Rapidfire-Plus
crankset
ACID MTB Hybrid Pro, 38T
cassette
Shimano Cues CS-LG300, 11-48T
chain
KMC eGlide
chain guide
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Cockpit
Stem
CUBE Performance Stem E-MTB 35, FPI-Link
handlebar
CUBE Rise Trail Bar 35
grips
ACID Hybrid Perform
Wheels
rims
CUBE EX30, 32H, Disc, Tubeless Ready
front hub
CUBE Engineered By Newmen, 15mm, Boost, 6-Bolt
rear hub
CUBE Engineered By Newmen, 12mm, Boost, 6-Bolt
tyres
Schwalbe Smart Sam, Active, 2.6
Finishing kit
saddle
ACID Sequence Pro 160
seat post
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
pedals
ACID PP MTB
front light
ACID Front Light PRO-E 150 X-Connect, 12V, DC
rear light
ACID Mudguard Rear Light PRO-E, 12V, DC
kickstand
ACID FM Pure Kickstand
mudguards
ACID 65
bell
ACID Alpha
carrier
ACID Carrier SIC 2.0 Rail Boost
Product information
colour
night´n´chrome
weight
27,2 kg
Art. No
801160
