Frame
frame
Aluminum Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points, Integrated Seatclamp
Suspension
Suspension fork
Fox 36 Float GRIP, 3-Position w/Micro Adjust, Tapered, 15x110mm, E-Bike Optimized, 130mm
shock
Fox Float EVOL, 185×52,5mm, Open/Firm Mode, Trunnion Mount
shock hardware
Top: 54mm Trunnion Mount, Bottom: 22.2x8mm
E-bike system
drive unit
Bosch Drive Unit Performance Line CX 85Nm (BDU38), Smart System
Remote
Bosch LED Remote
battery
Bosch PowerTube 800
display
Bosch Kiox 500
charger
Bosch 4A
Drivetrain & brakes
brake system
Magura Gustav PRO, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
rear derailleur
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
shifters
Shimano XT SL-M8100-IR, Direct Attach
crankset
ACID MTB Hybrid Pro, 38T
cassette
Shimano XT CS-M8100, 10-51T
chain
KMC e12
chain guide
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Cockpit
headset
ACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm), X-Connect Interface
Stem
CUBE Performance Stem E-MTB 35, FPI-Link
handlebar
CUBE Rise Trail Bar 35
grips
ACID Hybrid Perform
Wheels
wheelset
Newmen Performance 30, 28/32 Spokes (Base/Strong), 15x110mm / 12x148mm, Tubeless Ready
tyres
Schwalbe Johnny Watts 365, Performance, Kevlar, 2.6
Finishing kit
saddle
ACID Venec EMTB Plus 145
seat post
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
pedals
ACID PP MTB
Product information
colour
solareclipse´n´gold
weight
26,3 kg
Art. No
801500
