Frame
frame
Aluminium Superlite, Comfort Ride Geometry, Tapered Headtube, Premium Comfort And Safety, Semi-Integrated Carrier, Fully Integrated Battery, Slider Dropout
size
Easy Entry: XS / 46cm, S / 50cm, M / 54cm, L / 58cm
Suspension
Suspension fork
RockShox Paragon Gold Air, 50mm, Lockout
E-bike system
drive unit
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
Remote
Bosch LED Remote
battery
Bosch PowerTube 625
display
Bosch Kiox 500
charger
Bosch 4A
Drivetrain & brakes
brake system
Magura MT C ABS, Hydr. Disc Brake (180/180)
shifters
Enviolo AC-CLIQ Automatiq
crankset
ACID Trekking Hybrid, 50T
cassette
Gates Rear Sprocket E9 CDX, 24T
drive belt
Gates CDX, 128T
Cockpit
headset
ACROS AZF-1039, 1 1/8″ straight, Top Zero-Stack 1 1/8″ (ZS 44mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm)
Stem
CUBE Comfort Stem Pro, 31.8mm, Adjustable
handlebar
CUBE Comfort Shape Bar
grips
ACID Travel Comfort Gripshift
Wheels
rims
CUBE EX25, 32H, Disc, Tubeless Ready
front hub
Shimano HB-QB400, QR. 6-Bolt
rear hub
Enviolo Trekking, 380%, 6-Bolt, 135mm
tyres
Schwalbe Marathon E-Plus, 50-622
Finishing kit
saddle
ACID Shen Pro
seat post
BySchulz G.2 Parallelogram Suspension Seatpost, 30.9mm
pedals
ACID PP MTB
front light
ACID Front Light PRO-E 150, 12V, DC
rear light
ACID Mudguard Rear Light PRO-E, 12V, DC
kickstand
ACID FM Pure Kickstand
mudguards
ACID 56 BB-Mount
bell
ACID Alpha
carrier
ACID Semi-Integrated Carrier, ACID RILink Adapter Compatible
Product information
colour
golddust´n´black
weight
29,7 kg
Art. No
813700
